HFJV1-1G46RL HFJV1-E1G46RL Vertical RJ45 MagJack Without Leds

Name: HFJV11G46RL HFJV1E1G46RL Vertical RJ45 MagJack Without Leds
Brand: LINK-PP
Price: 0.09 USD

Brand Name : LINK-PP

Model Number : HFJV1-1G46RL

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : $0.09-$3.85

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4200K-PCS/Month

Delivery Time : in Stock Ship Today

Packaging Details : 50pcs/tray,1200pcs/carton

Part Number : HFJV1-1G46RL / HFJV1-E1G46RL

Equivalent : LPJD0718DNL

Hi-Pot : 1500Vrms

OCL : 350uH Min at 8mA DC Bias

PHY Drive : Voltage

Type : Vertical RJ45 Connector With 1000 Magnetic

Contact Now

HFJV1-1G46RL & HFJV1-E1G46R Vertical RJ45 Connectors Overview

1x1 vertical shielded Gigabit RJ45 MagJack with integrated transformers, IEEE-802.3 compliant, available in standard (HFJV1-1G46RL) and industrial-temperature versions (HFJV1-E1G46RL) for networking and industrial applications.

Key Features

1-port RJ45 Connector with integrated magnetics
Supports 10/100/1000Base-T Ethernet
Without LEDs
Compatible with PoE / PoE+ (IEEE 802.3af/at)
Low cross-talk & superior EMI suppression
TOP-Entry Mounting
RoHS-compliant, Halogen-free options available
Shielded housing for noise immunity

Electrical Specifications

Parameter	Specification
Ethernet Speed	10/100/1000 Mbps
Transformer Ratio	1:1 (Gigabit)
Compliant	IEEE 802.3 compliant
HI-POT	1500VAC, 60s
Insulation Resistance	≥ 500MΩ
Contact Resistance	≤ 40mΩ
Insertion/Withdrawal Cycles	750+ cycles

Mechanical & Environmental

Parameter	HFJV1-1G46RL / HFJV1-E1G46RL
Connector Type	RJ45 Magnetic Jack
Port Count	1 port
LED	No LEDs
Orientation	Top-Entry
Shield	Yes
Operating Temperature	0°C to +70°C / -40°C to +85°C
Storage Temperature	-40°C to +85°C
Humidity	0–95% RH

HFJV1-1G46RL / HFJV1-E1G46RL 1000 Base-T RJ45 Vertical Jack Circuit:
